Grey Deutsch DT Connector 3 Way Y piece DT043PP007

Grey Deutsch DT Connector  3 Way Y piece DT043PP007
Grey Deutsch DT Connector  3 Way Y piece DT043PP007
Grey Deutsch DT Connector  3 Way Y piece DT043PP007
Grey Deutsch DT Connector  3 Way Y piece DT043PP007
Grey Deutsch DT Connector  3 Way Y piece DT043PP007
Grey Deutsch DT Connector  3 Way Y piece DT043PP007
Grey Deutsch DT Connector 3 Way Y piece DT043PP007
£25.24
Ex Tax: £21.03
  • Availability: In Stock
  • Brand: TE Connectivity
  • Product Code: DT04-3P-P007
  • Weight: 0.23kg
  • Dimensions: 44.00mm x 24.71mm x 48.01mm

DT04-3P-P007 is a receptacle "y" connector. The rugged field proven DT 3 pin connector designed to meet the SAE requirements for 3-wire CAN applications linking ECUs for serial data communications.

For use with DT series Pin contacts


Technical Data

Thermoplastic Body

IP68

Current Rating 13A

Width : 24.71 mm

Height : 48.01 mm

Length : 44 mm

Operating Temperature Range : -55 – 125  degrees C

Electrical Specification
Current (A) 13A
Approval
Approval Type IP68
