Split Charger 24V DC to 24V DC 10A 085253

24 volt dc to 24 volt dc 10 amp split charger.  Designed to charge and maintain a sepaate 24 volt battery from a 24 volt dc system.  It has a three stage micro processor controlled charging system and uses voltage sensing for automatic cut in and drop out of charge from the 24 volt system, so will not charge the 24 volt battery until the 24 volt battery on the main vehicle is charged or being charged.

Automatic 3 stage charging: Constant current, constant voltage and float

Charge status LED indication

Reverse polarity and short circuit protection

Auto cut in and drop out

Isolates different voltage systems

Output controlled to maximum current

Can be permanently connected

Will not discharge the vehicles batteries.

Additional Information

Red LED Main charge (constant current)

Flashing Red Final charge (constant voltage)

Green LED Float charge

No LED Input below 25.2 volt, split charger off
